Our machine designs are developed in close collaboration with our customers. We don’t just adapt individual components or auxiliary units; instead, we tailor each machine specifically to meet the respective requirements, processes, and production goals. Whether it’s a proven standard solution or a custom design, our systems can be flexibly adapted to a wide variety of tasks.
Our customized handling solutions can transport finished rolls directly to downstream processes or to the packaging area via robotic or conveyor systems. Through close collaboration with our customers, we implement both proven concepts and sophisticated custom solutions, creating tailor-made automation solutions for every application.
| Working width | 31,5 – 98,4 in. |
| Parent roll weight | 6613,9 lb |
| Unwinding diameter | Ø 63 in. |
| Core diameter | Ø 2 – 7,9 in. |
| Slitting systems Cutting system | shear cut, blade groove cut, crush cut |
| Slitting width | min. 0,3 in. |
| Rewind diameter | max. Ø 31,5 in. on both winding levels or optionally Ø 39,4 in. on the lower winding level |
| Machine speed | max. 2624,7 fpm |
| Materials | technical films, packaging films, soft and hard films, papers, laminates, aluminum composite materials |
